Ford 40 Series Torque Settings

 Identify the torque settings for your Ford 40 series tractor.

VALVE LASH CLEARANCE (COLD)



Exhaust
0.017-0.021 in (0.43-0.53mm)

Intake
0.014-0.018 in (0.36-0.46mm)

PISTON RINGSGAP WIDTH
Top Compression
0.015-0.033 in (0.38-0.84mm)

2nd Compression
0.026-0.044 in (0.66-1.12mm)

CRANK JOURNAL DIAMETER


Main Diameter
3.3713-3.3718 in (85.631-85.644mm)

Big End Diameter
2.750-2.7504 in (69.850-69.860mm)

CRANK BOLTS TORQUE
Lb ft
Nm
Mains
145 lb ft
197 Nm
Rod Bolts
110 lb ft
149 Nm
Head Bolts Engine Cold
160 lb ft
217 Nm
Flywheel Bolts
145 lb ft
197 Nm
Sump to block (Cast)
28 lb ft
38 Nm
